1.5.2 Interface
1 I / O alarm terminal block (Only FI9805E)
This network camera provides a I/O alarm terminal block which is used to connect to external input / output
device.
The pin (there are four number in the terminal block from no. 1 to no. 4) definitions are as follows:
This camera supports I/O alarm, you can go to Settings-Alarm - I/O page to configure it.
2 LAN
10/100M adaptive Ethernet interface. Through this interface, IP camera can be connected with various network
devices, such as hub, router, etc.
3 Reset button
Press and hold on the reset button for 5 seconds. Releasing the reset button, the password will back to the
factory default administrator password. The default administrator user is admin with no password.
4 Power Interface
1
2
3
4
5
6
7
1– input
2- input
3- output
4- output
