Foster + Freeman VSC 80 - VSC80 Main Unit; Overview and Configurations

6
VSC
®
80: Main unit (Illumination modes)
VSC
®
80: Main unit
Video camera
Light sources
Optical filters
▪▪▪▪▪▪
Translucent panel
USER GUIDE
( (0280-004-02) Copyright © Foster + Freeman Ltd
The VSC
®
80 is a powerful PC-based imaging system for examining documents of all types. The
document to be examined is placed on the platen under the canopy and a video image displayed on the
monitor. The VSC
®
80 main unit is controlled by the PC system and VSC
®
software. Alternative
configurations are available:
• PC system + VSC Software Suite:
• Embedded PC + Touchscreen monitor:
VSC
®
80: Main unit
VSC
®
80i: Touchscreen monitor
 
 
VSC
®
80: Main unit
PC system
VSC
®
software
CD-ROM
Desktop icon
VSC
®
80: MAIN UNIT
