Foster + Freeman VSC 80 - Imaging System; Document Platen; Video Camera FULL HD; Spectral Response

9
USER GUIDE
VSC
®
80: Main unit (Illumination modes)
VSC
®
80: Main unit
Video camera
Light sources
Optical filters
▪▪▪▪▪▪
Translucent panel
VSC
®
80: Document platen
Y
X
Translucent panel
Document platen
Field of view (User defined)
pixels
VSC
®
80: Video camera (Spectral response)
Wavelength (nm)
Video camera
The VSC
®
80 is a powerful PC-based imaging system for examining documents of all types. The
document to be examined is placed on the platen under the canopy and a video image displayed on the
monitor:
Document platen
Video camera FULL HD
VSC is equipped with high-definition imaging cameras of type CMOS, which has an optical view of not x80 and
Full HD video signal, autofocus. Adjustable dynamic focal range, with a resolution of 1920 x 1080 pixels
Spectral response
Video camera
▬▬
Red
▬▬
Green
▬▬
Blue
 
 
Document platen
Translucent panel
X (mm)
378
229
Y (mm)
320
135
Tilt angle
0
o
VSC
®
80: IMAGING SYSTEM
m
m
VSC
®
80: Camera image
▲
1080
pixels X/Y XY Mpixels
X 1920
▀▀▀▀▀▀▀
▼
Y 1080
16/9
2.13
◄
1920
►
