VC-8
3
TABLE OF CONTENTS
NOTES
* Parts List and circuit diagrams are given in this manual to assist the service technician in
maintaining the Model VC-8.
* The following accessories are supplied with VC-8 as the standard accessories.
Owner's manual, VC-8, MLT : 8288444000
AC adaptor AD-12A : 8270727003 (for USA/CND)
: 8270727006 (for EUR)
: 8270727007 (for UK)
: 8270727010 (for JPN)
* Following is the packing material for the Model VC-8.
PACK, SIDE, L, DE-1 : 8228454000
PACK, SIDE, R, DE-1 : 8228455000
CARTON, INNER, VC-8 : 8228727000
CARTON, OUTER, VC-8 : 8228906000
1. SPECIFICATIONS.............................................................................................4
2. CONTROLS, INDICATORS AND CONNECTORS..................................... 5
3. EXPLODED VIEW ...........................................................................................6
4. PARTS LIST......................................................................................................8
5. PCB PATTERN DRAWING..........................................................................10
6. CIRCUIT DIAGRAMS ...................................................................................12
CAUTION
Parts marked with this sign are safety critical components. They must always be replaced
with identical components. Refer to the Fostex Parts List and ensure exact replacement.
