Fostex VC-8 Service Manual

VC-8
8
• MAIN PCB ASSY
Ref. No. Part No. Description
8274201000 PCB_ASSY, VC-8
B101 8251525200 PLAIN_PCB, VC-8
ICs
Ref. No. Part No. Description
U001 8236541610 ST, AN, REGULATOR, UPD29M10T
U002~004 8236540301 ST, AN, REGULATOR, L78M05T-TL
U005 8236545904 ST, TSSOP, 74VHCU04
U006 8236085000 QFP, DG, GATE_ARRAY, DIF
U007 8236502500 ST, AN, RESET, NJM2103M
U008, 009 8236545163 ST, TSSOP, TC74VHC163
U010, 011 8236545153 ST, TSSOP, TC74VHC153
U012 8236503400 ST, DG, VCO, TC9246F
U013, 014 8236570101 ST, DG, DRIVER, DTC114EK
U015~017 8236545074 ST, TSSOP, 74VHC74
U018 8236545000 ST, TSSOP, 74VHC00
U019 8236545161 ST, TSSOP, 74VHC161
U020 8236545086 ST, TSSOP, 74VHC86
U021, 022 8236570101 ST, DG, DRIVER, DTC114EK
U023 8236570801 ST, DG, DRIVER, DTB114TK
U024 8236545074 ST, TSSOP, 74VHC74
U025 8236545904 ST, TSSOP, 74VHCU04
U026 8236503400 ST, DG, VCO, TC9246F
U027 8236570401 ST, DG, DRIVER, DTA114EK
U029, 030 8236545157 ST, TSSOP, 74VHC157
U031 8236545000 ST, TSSOP, 74VHC00
U032 8236541300 ST, AN, DC-DC, NJM2360AM
U034, 035 8236570401 ST, DG, DRIVER, DTA114EK
U101~801 8236505011 ST, AN, OPAMP, NJM2115M(TEI)
U151~451 8236541700 ST, DG, ADDA, AK4522
U153~453 8236541200 ST, AN, OPAMP, NJM4565M
U157~857 8236570201 ST, DG, DRIVER, DTC314TK
DIODEs
Ref. No. Part No. Description
D001 8234101400 OPT, VT, LED, GRN, LT3K8B
D002 8234502800 D, ST, DAN202K
D003 8234750600 D, ST, RB400D
D004 non
D005 8234202700 OPT, V, LED, GRN-RED, GL3ED8
D006, 007 8234502800 D, ST, DAN202K
D008 8234108400 D, VT, SCHOTTKEY, EK03W
D009~011 8234502800 D, ST, DAN202K
RESISTORs
Ref. No. Part No. Description
R001 8230500681 ST, CARBON, 1/10W, 680, 5%
R002 8230500101 ST, CARBON, 1/10W, 100, 5%
R003 8230500332 ST, CARBON, 1/10W, 3.3K, 5%
R004 8230500222 ST, CARBON, 1/10W, 2.2K, 5%
R005 8230500105 ST, CARBON, 1/10W, 1M, 5%
R006 8230500000 ST, CARBON, 1/10W, 0, 5%
R007 8230500101 ST, CARBON, 1/10W, 100, 5%
R008 8230500561 ST, CARBON, 1/10W, 560, 5%
RESISTORs
Ref. No. Part No. Description
R009 8230500331 ST, CARBON, 1/10W, 330, 5%
R010 8230500101 ST, CARBON, 1/10W, 100, 5%
R011~013 8230500103 ST, CARBON, 1/10W, 10K, 5%
R014 8230500101 ST, CARBON, 1/10W, 100, 5%
R015 8230500751 ST, CARBON, 1/10W, 750, 5%
R016 8230500472 ST, CARBON, 1/10W, 4.7K, 5%
R017 non
R018 8230500331 ST, CARBON, 1/10W, 330, 5%
R019 non
R020, 021 8230500101 ST, CARBON, 1/10W, 100, 5%
R022 non
R023 8230500102 ST, CARBON, 1/10W, 1K, 5%
R024, 025 8230500103 ST, CARBON, 1/10W, 10K, 5%
R026 8230508101 R, ST, ARRAY, 100x4, 5%, CN1J4
R027 8230500101 ST, CARBON, 1/10W, 100, 5%
R029 8230500103 ST, CARBON, 1/10W, 10K, 5%
R030 8230500222 ST, CARBON, 1/10W, 2.2K, 5%
R031, 032 8230500102 ST, CARBON, 1/10W, 1K, 5%
R033, 034 8230500104 ST, CARBON, 1/10W, 100K, 5%
R035 8230500561 ST, CARBON, 1/10W, 560, 5%
R036 8230500152 ST, CARBON, 1/10W, 1.5K, 5%
R037 8230500224 ST, CARBON, 1/10W, 220K, 5%
R038, 039 8230500101 ST, CARBON, 1/10W, 100, 5%
R040 8230500681 ST, CARBON, 1/10W, 680, 5%
R041~043 8230500101 ST, CARBON, 1/10W, 100, 5%
R044 8230500681 ST, CARBON, 1/10W, 680, 5%
R045 8230500104 ST, CARBON, 1/10W, 100K, 5%
R048 8230500104 ST, CARBON, 1/10W, 100K, 5%
R049 8230500103 ST, CARBON, 1/10W, 10K, 5%
R050, 051 8230500101 ST, CARBON, 1/10W, 100, 5%
R054 8230500103 ST, CARBON, 1/10W, 10K, 5%
R055 8230500101 ST, CARBON, 1/10W, 100, 5%
R056 8230500750 ST, CARBON, 1/10W, 75, 5%
R057 8230500103 ST, CARBON, 1/10W, 10K, 5%
R058 8230500159 ST, CARBON, 1/10W, 1.5, 5%
R059 8230500105 ST, CARBON, 1/10W, 1M, 5%
R060, 061 8230500561 ST, CARBON, 1/10W, 560, 5%
R062 8230500103 ST, CARBON, 1/10W, 10K, 5%
R063, 064 8230500473 ST, CARBON, 1/10W, 47K, 5%
R065 8230500101 ST, CARBON, 1/10W, 100, 5%
R101~801 8230500183 ST, CARBON, 1/10W, 18K, 5%
R102~802 8230500752 ST, CARBON, 1/10W, 7.5K, 5%
R103~803 8230500103 ST, CARBON, 1/10W, 10K, 5%
R104~804 8230500103 ST, CARBON, 1/10W, 10K, 5%
R105~805 8230500331 ST, CARBON, 1/10W, 330, 5%
R106~806 8230500331 ST, CARBON, 1/10W, 330, 5%
R109~809 8230500104 ST, CARBON, 1/10W, 100K, 5%
R111~811 8230500103 ST, CARBON, 1/10W, 10K, 5%
R112~812 8230500123 ST, CARBON, 1/10W, 12K, 5%
R113~813 8230500222 ST, CARBON, 1/10W, 2.2K, 5%
R114~814 8230500104 ST, CARBON, 1/10W, 100K, 5%
R151~451 8230500100 ST, CARBON, 1/10W, 10, 5%
R152~452 8230500101 ST, CARBON, 1/10W, 100, 5%
R153~453 8230500100 ST, CARBON, 1/10W, 10, 5%
R156~856 8230500101 ST, CARBON, 1/10W, 100, 5%
4. PARTS LIST
