VC-8
9
CAPACITORs
ALU = Electrolytic type
CER = Ceramic type
Ref. No. Part No. Description
C001~003 8232143106 VT, ALU, 16V, 10µF, 20%, SME-VB
C004 8232142107 VT, ALU, 10V, 100µF, 20%, SME-VB
C005~008 8232143106 VT, ALU, 16V, 10µF, 20%, SME-VB
C009 8232143477 VT, ALU, 16V, 470µF, 20%, SME-VB
C010~012 8232143106 VT, ALU, 16V, 10µF, 20%, SME-VB
C013~020 8233502104 ST, CER, 50V, 0.1µF, +80, CC20F
C021~024 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C025 8233500471 ST, CER, 50V, 470pF, 5%, CC20SL
C026, 027 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C028, 029 8233500471 ST, CER, 50V, 470pF, 5%, CC20SL
C030~034 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C035 8233502104 ST, CER, 50V, 0.1µF, +80, CC20F
C036~042 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C043, 044 8233500101 ST, CER, 50V, 100pF, 5%, CC20SL
C045 8233500470 ST, CER, 50V, 47pF, 5%, CC20SL
C046 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C047, 048 8233500220 ST, CER, 50V, 22pF, 5%, CC20SL
C049~051 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C052 8233500150 ST, CER, 50V, 15pF, 5%, CC20SL
C053 8233509474 ST, CER, 25V, 0.47µF, 20%, KC30E
C054 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C055 8232144107 VT, ALU, 25V, 100µF, 20%, SME-VB
C056 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C057 8232142107 VT, ALU, 10V, 100µF, 20%, SME-VB
C058 8233502104 ST, CER, 50V, 0.1µF, +80, CC20F
C059~062 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C063 8233500222 ST, CER, 50V, 0.0022µF, 5%, CC20SL
C064 8232143107 VT, ALU, 16V, 100µF, 20%, SME-VB
C065 8232143476 VT, ALU, 16V, 47µF, 20%, SME-VB
C066 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C067 non
C068, 069 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C070 8232143106 VT, ALU, 16V, 10µF, 20%, SME-VB
C071 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C072 8233502104 ST, CER, 50V, 0.1µF, +80, CC20F
C073 8233509474 ST, CER, 25V, 0.47µF, 20%, KC30E
C074 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C075 8233500150 ST, CER, 50V, 15pF, 5%, CC20SL
C076 8233500470 ST, CER, 50V, 47pF, 5%, CC20SL
C077 8232357477 VT, ALU, 16V, 470µF, 20%, LXV, D10
C078 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C079~081 8233502104 ST, CER, 50V, 0.1µF, +80, CC20F
C101~801 8232143106 VT, ALU, 16V, 10µF, 20%, SME-VB
C102~802 8233500152 ST, CER, 50V, 0.0015µF, 5%, CC20R
C103~803 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C104~804 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C107~807 non
C108~808 non
C111~811 8232143106 VT, ALU, 16V, 10µF, 20%, SME-VB
C112~812 8233500681 ST, CER, 50V, 680pF, 5%, CC20SL
C113~413 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
CAPACITORs
Ref. No. Part No. Description
C114 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C115~815 non
C116~816 8232143107 VT, ALU, 16V, 100µF, 20%, SME-VB
C151~451 8232143106 VT, ALU, 16V, 10µF, 20%, SME-VB
C152~452 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C153~453 8232143106 VT, ALU, 16V, 10µF, 20%, SME-VB
C154~454 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C155~455 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C156~456 8232143106 VT, ALU, 16V, 10µF, 20%, SME-VB
C157~457 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C158~458 8232143106 VT, ALU, 16V, 10µF, 20%, SME-VB
C314 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C514 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
C714 8233504103 ST, CER, 25V, 0.01µF, 10%, CC20R
MISCELLANEOUS
Ref. No. Part No. Description
J001 8245541000 CONN, PL, JACK, DC-INLET,
YKB31-0012
J002 8245552010 CONN, OPT, GPIF38T2
J003 8245553010 CONN, OPT, GPIF37R1
J004 8245325000 CONN, PL, JACK, BNC, YKS11-0011
J101~104 8245286000 CONN, PL, JACK, RCA, 4P,
YKC21-3077
L001, 002 8242502560 CORE, ST, CDRH104, 56µH
L003 8242196223 COIL, PVT, 22µH, 5%, LF5.0S
L004 8242134001 FILTER, EMI, 6HOLE
L005 8242196223 COIL, PVT, 22µH, 5%, LF5.0S
L006 8242501121 FILTER, ST, EMI, 120, 25%,
MMZ2012S
L007 8242503221 CORE, ST, CDPH73, 220µH
L101~801 8242501121 FILTER, ST, EMI, 120, 25%,
MMZ2012S
L102~802 8242501121 FILTER, ST, EMI, 120, 25%,
MMZ2012S
S001 8253457002 SW, PI, SLIDE, 1-3, NONSH,
SSSS91, L4
S002, 003 8253655002 SW, SLIDE, 2-3, NONSH, SSSF1
S004 8253655018 SW, PL, SLIDE, 2-2, NONSH,
SSSF122, L06, COVER
S005 8253655017 SW, PL, SLIDE, 1-2, NONSH,
SSSF1, L06, COVER
S007 8253655017 SW, PL, SLIDE, 1-2, NONSH,
SSSF1, L06, COVER
X001 8256170005 RESONATOR, ST, XTL,
11.2896MHZ, FUP-FBB3A
Y701 8276873002 TUBE, UL, BLACK, 1, L05
