Fourgroup Xtreme Series - Maximum Continuous Operation

22
To move to the next horizontal parameter press the button :
To set the maximum time of continuous operation of the pump is necessary to pass to the parameter "Max Continuous
working" by pressing
:
To continue programming the parameters of the pump press the button
to go back to the parameter “Enable Max
Cont. working”:
To move to the next horizontal parameter press the button
:
P1 Alarm Delay
Cosφ XXsec
The parameter “P1 Alarm Delay Cosφ” will set the time delay for the activation of the alarm for
minimum Cosφ (the lowering of the Cosφ value is an indication that the pump is not sucking
water and it’s working in dry condition): the threshold must be crossed (dry running condition)
for the amount of time specified for the alarm to trigger and to stop the pump.
For example, if the alarm time delay is set to10 seconds and the threshold is crossed
continuously for 10 seconds for the alarm to activate; if the threshold is crossed for less than
10 seconds the alarm will not activate.
The “X” indicates the setting of the parameter to modify.
The range of value is from 1 to 120 seconds.
Factory default setting: 3 seconds.
Enable Max Cont.
Working 0=NO X
P1 Alarm Delay
Cosφ XXsec
Enable Max Start
Minute 0=NO X
Enable Max Cont.
Working 0=NO X
The parameter “Enable Max Continuous working operation” will enable/disable the alarm for the
maximum continuous operation of the pump. When enabled and the pump is continuously
working for a period of time over the value set then the alarm will be activated and the pump
will be stopped. The functional operation of the pump will be inhibited until the reset of the
alarm (pressing the button
of the pump in “status of alarm”).
The “X” indicates the setting of the parameter to modify.
0=NO: setting “0” will disable the alarm for max continuous working condition of the pump.
1=YES: setting “1” will enable the alarm for max continuous working condition of the pump.
Factory default setting: 0 (disable).
The parameter “Max Continuous working” will set maximum time of continuous working
operation of the pump. If the pump works continuously for a period of time longer than the set
value then the pump will be stopped and the alarm will trigger. The functional operation of the
pump will be inhibited until the reset of the alarm (pressing the button
of the pump in
status of alarm).
The “X” indicates the setting of the parameter to modify.
The range of value is from 1 to 9999 minutes.
Factory default setting: 1440 minutes (24hours).
Enable Max Cont.
Working 0=NO X
P1 Alarm Delay
Cosφ XXsec
Enable Max Start
Minute 0=NO X
Max Continuous
working XXXXmin
Enable Max Start
Minute 0=NO X
Enable Max Cont.
Working 0=NO X
Enable Max Start
Hour 0=NO X
Enable Max Cont.
Working 0=NO X
Max Continuous
working XXXXmin
