30
The setting of all the parameters for the program operating mode DIGIT is complete.
Refer to section “INSTALLATION EXAMPLES” for directions of the connections and the applications of the mode DIGIT.
Similarly of the previous program operating mode, it is possible to select “Program PAUSE/WORK” and set all its
parameters.
To proceed and set all the parameters of the operating mode PAUSE/WORK press the button
:
To move to the next horizontal parameter press the button :
To move to the next horizontal parameter press the button :
To move to the next horizontal parameter press the button
:
Enable
DIGIT
Operating mode
Empty/Fill X
Enable
DIGIT
The parameter “Enable DIGIT” will enable/disable the program operating mode DIGIT. Once
enable the mode DIGIT it will apply to all the installed pumps.
To enable the operating mode DIGIT press the button
to save its setting. The display will
show briefly the message “save” as confirmation that the setting has been saved. In the main
display the word “Dig” will show to indicate the selected program operating mode.
NOTE: the setting of the alarm level/pressure and commands of the pumps of operating mode DIGIT are
under the submenu “Enable 4-20 mA” of the menu “General Settings”. The setting of the level/pressure
needs to be consistent with the logical of operating mode selection (empty or fill).
Pause Time
P1 XXXmin
Starting cycle
Pause/Work X
Pause Time
P1 XXXmin
With the parameter "Pause Time P1" is possible to set the duration of the pause time in the
operation of the pump P1.
The “X” indicates the setting of the parameter to modify.
The range of value is from 1 to 999 minutes.
Factory default setting: 200.
Work Time
P1 XXXmin
Pause Time
P1 XXXmin
Work Time
P1 XXXmin
With the parameter "Work Time P1" is possible to set the duration of working time in the
operation of the pump P1.
The “X” indicates the setting of the parameter to modify.
The range of value is from 1 to 999 minutes.
Factory default setting: 100.
With the parameter "Starting cycle Pause/Work" is possible to select if the operating program
"PAUSE/WORK" must start the operating cycle from the pause time or work time.
The “X” indicates the setting of the parameter to modify.
0=PAUSE
1=WORK
Factory default setting: 0.
Program
PAUSE/WORK
Starting cycle
Pause/Work X
