MACHINE IDENTIFICATION
1. ON / OFF switch
2. Electric cable
3. Rubber coating
4. Saw blade stop
5. Machine basement
6. Dust collection outlet
7. Lower saw blade wheel
8. Upper saw blade wheel
9. Saw blade tension adjustment knob
10. Upper saw blade protection
11. Upper blade guide
12. Door
13. Door fastening
14. Upper saw blade wheel blocking
15. Workbench
16. Worbench angle indicator
17. Workbench insert
18. Workbench angle locking lever
19. Saw blade guide adjustment knob
20. Saw blade guide locking knob
21. Rip fence locking lever
22. Upper saw blade wheel adjustment knob
23. Motor
24. Rip fence
25. Machine frame
26. Bandsaw saw blade
ASSEMBLY
WORKBENCH ASSEMBLY (Fig. 3, 4 and 5)
a.
Remove saw blade stop
(4) Fig.3.
b.
Place the workbench
(15) Fig.1
on the frame of the machine
(25) Fig.2
, and fix it with 3 screw
(27)
as
showed in
Fig.4.
Place the saw blade
(26)
Fig.2
in order that is is exactly at the centre of the workbench.
c.
Put the saw blade stop in its position
(4) Fig.2.
d.
Assemble the workbench insert
(17) Fig.5
in order that the hole is aligned to the workbench slot.
e.
To disassemble the workbench, follow the instructions of this paragraph in reverse order.
