Fox PERFORMANCE ELITE 2.5 - Supplied Part S

605-01-3 67 2
FRONT SHOCK SUPPLIED PARTS
FRONT SHOCK ASSEMBLY
FOX PN DESCRIPTION QTY NOTES
883-06-218-L/R LEFT/RIGHT SHOCK 2 UCAs are required.
FRONT RESERVOIR BRACKET ASSEMBLY
FOX PN DESCRIPTION QTY NOTES
026-01-095-1 LEFT RESERVOIR BRACKET 1 Brackets mount the
remote reservoirs
to the vehicle.
026-01-095-2 RIGHT RESERVOIR BRACKET 1
026-01-284 SWAY BAR RELOCATION BLOCK 2
The sway bar
mounts to the relo-
cation bracket.
026-01-285 SWAY BAR RELOCATION BLOCK 2
The sway bar
mounts to the relo-
cation bracket.
019-01-245 SWAY BAR BLOCK SCREWS 4
Screws fasten the
brackets to the
vehicle’s frame.
026-01-286 BUMP STOP SPACER 2
Install spacers if
preload is in-
creased.
018-01-066 SCREW: 8-32, 3/4” 4 Each bracket uses
two clamps and
a clamp uses two
screws.
026-01-167-1 2.5 RESERVOIR CLAMP, TOP 2
026-01-167-2 2.5 RESERVOIR CLAMP, BOTTOM 2
