Fox PERFORMANCE ELITE 2.5 - Shock Diagram

605-01-3 67 4
SHOCK DIAGRAM
7
6
2
2 75
11
4
3
9
12
9
8
10
8
1
1
PART NO. NAME PART NO. NAME
1 Eyelet 7 DSC adjuster
2 Hose 8 Reservoir
3 Stem top 9 Shock body
4 Shaft 10 Schrader valve
5 Hose fitting 11 Top hat
6 Preload ring 12 Shock Boot
FRONT SHOCK REAR SHOCK
