Foxconn H67M-V User Manual

1
3
Internal Connectors 1 x LPT connector
1 x CD_IN connector
1 x Chassis intrusion alarm header (INTR)
1 x CLR_CMOS jumper
Back Panel 1 x PS/2 port
Connectors 1 x VGA port
1 x DVI-D port
6 x USB 2.0 ports
1 x RJ-45 LAN port
1 x HDMI port (H67M-S/H67M)
2 x USB 3.0 ports (H67M-S)
8-channel Audio ports (H67M-S/H67M)
6-channel Audio ports (H67M-V)
Hardware Monitor System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU overheating warning
CPU/System fan speed control
PCI Express x1 Support 250MB/s (500MB/s concurrent) bandwidth
Low power consumption and power management features
PCI Express x16 Gen2.0 Support 8GB/s (16GB/s concurrent) bandwidth
Low power consumption and power management features
Green Function Support ACPI (Advanced Conguration and Power Interface)
Support S0 (normal), S1 (power on suspend), S3 (suspend to RAM),
S4 (suspend to disk), S5 (soft - off)
Support EuP Function
Bundled Software FOX ONE
FOX LiveUpdate
FOX LOGO
FOX DMI
Operating System Support for Microsoft® Windows®
7/Vista/XP
Form Factor Micro ATX Form Factor, 9.6 inches x 8.8 inches (24.4cm x 22.4cm)

Foxconn H67M-V Specifications

General

Form Factor	Micro ATX
Chipset	Intel H67
Socket	LGA 1155
Maximum Memory	32GB
Memory Standard	DDR3 1333/1066 MHz
PCI Express x16	1
SATA Ports	4 x SATA 3Gb/s, 2 x SATA 6Gb/s
Audio	Realtek ALC887 8-Channel HD Audio
Memory Slots	4
Expansion Slots	1 x PCI
USB Ports	10 (4 on back panel, 6 via headers)
Video Outputs	DVI-D
LAN	Realtek RTL8111E Gigabit LAN
