Foxconn H67M-V User Manual

3
37
Health
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Advanced Chipset Boot Power Health Security Save & Exit
Case Open Warning [Disabled]
CPU Temperature : +86 C
System Temperature : +35 C
CPU Fan Speed : 2149 RPM
System Fan 1 Speed : N/A
CPU Vcore : +0.972 V
DRAM Voltage : +1.608 V
+12V SYS : +11.971 V
+5V SYS : +3.002 V
VBAT : +3.120 V
Smart Fan Function [Disabled]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Case Open Warning
Health
► Case Open Warning
This item is used to enable or disable case open warning function.
► CPU Temperature
These items show the current CPU temperature detected automatically by the system.
► System Temperature
These items show the current System temperature detected automatically by the system.
► CPU Fan Speed
This item shows the current CPU Fan speed detected automatically by the system.
► System Fan 1 Speed
This item shows the current North Bridge Fan speed detected automatically by the system.
► CPU Vcore/DRAM Voltage/+12V SYS/+5V SYS/VBAT
These items show the Current CPU Ccore/DRAM/+12V SYS/+5V SYS/VBAt voltage detected
automatically by the system.
► Smart Fan Function
This option is used to enable or disable smart fan function. Default value is [Disabled]. Only
when this option is enabled, you can set some correlative parameters. "Smart Fan Automatic
Mode" is the principle gure of CPU smart fan function for your reference.

Foxconn H67M-V Specifications

General

Form Factor	Micro ATX
Chipset	Intel H67
Socket	LGA 1155
Maximum Memory	32GB
Memory Standard	DDR3 1333/1066 MHz
PCI Express x16	1
SATA Ports	4 x SATA 3Gb/s, 2 x SATA 6Gb/s
Audio	Realtek ALC887 8-Channel HD Audio
Memory Slots	4
Expansion Slots	1 x PCI
USB Ports	10 (4 on back panel, 6 via headers)
Video Outputs	DVI-D
LAN	Realtek RTL8111E Gigabit LAN
