Recovery Volume Options
1. “Recovery Volume Options” is only available when “Recovery” is built. Here, we take
TryRecovery as an example, select “4. Recovery Volume Options” in main menu
and press <Enter>. The screen displays:
2. Use Up or Down key to make a selection to enable Recovery or Master disk.
3. Here, we select “1.Enable Only Recovery Disk“ and press<Enter> to continue. The
screen display:
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
1. Enable Only Recovery Disk
2. Enable Only Master Disk
Enable Only Recovery Disk - enables recovery disk if avaliable and
disables master disk.
Enable Only Master Disk - enables master disk if avaliable and
disables master disk.
Actions will result in change from Contious Update mode to On-Request.
Intel(R) Rapid Storage Technology - Option ROM - 10.0.0.1032
Copyright(C) 2003-10 Intel Corporation. All Rights Reserved.
1. Enable Only Recovery Disk
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
[ HELP ]
[ RECOVERY vOLUME OPTIONS ]
Name Level Capacity Status Bootable
TryRecovery Recovery(Cont.) 74.5GB Normal Yes
Select a Recovery volume to do the operation.
[↑↓]-Up/Down [SPACE]-Selects [ENTER]-Done
[ SELECT RECOVERY VOLUME]
TryRecovery Recovery(Cont.) 74.5GB Normal Yes
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
1. Enable Only Recovery Disk
2. Enable Only Master Disk
Enable Only Recovery Disk - enables recovery disk if avaliable and
disables master disk.
Enable Only Master Disk - enables master disk if avaliable and
disables master disk.
Actions will result in change from Contious Update mode to On-Request.
Intel(R) Rapid Storage Technology - Option ROM - 10.0.0.1032
Copyright(C) 2003-10 Intel Corporation. All Rights Reserved.
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
[ HELP ]
[ RECOVERY vOLUME OPTIONS ]
1. Enable Only Recovery Disk

Foxconn H67M-V Specifications

General

Form Factor	Micro ATX
Chipset	Intel H67
Socket	LGA 1155
Maximum Memory	32GB
Memory Standard	DDR3 1333/1066 MHz
PCI Express x16	1
SATA Ports	4 x SATA 3Gb/s, 2 x SATA 6Gb/s
Audio	Realtek ALC887 8-Channel HD Audio
Memory Slots	4
Expansion Slots	1 x PCI
USB Ports	10 (4 on back panel, 6 via headers)
Video Outputs	DVI-D
LAN	Realtek RTL8111E Gigabit LAN
