Create RAID 1 (Mirroring)

1. Select “Mirroring” from the RAID Mode.

2. Select two hard disks to build our RAID1 system.

3. Press [TAB] to navigate to left drive panel, then use [→] and [↓] keys to add the hard

disks to the right drive panel.

MediaShield Utillity Apr 26 2007

- Dene a New Array -

RAID Mode: Mirrored Stripe Block: Optimal

Free Disks Array Disks

Port Disk Model Capacity Port Disk Model Capacity

[-›] Add

[‹-] Del

[ESC] Quit [F6] Back [F7] Finish [TAB] Navigate [↑↓] Select [ENTER] Popup

Optimal

0.0 WDC WD1200JD-9 111.79GB

1.1 Hitachi HDT725 232.88GB

2.0 HDS728080PLA38 76.69GB

2.1 ST3320620AS 298.09GB

Mirroring

1.0 WDC WD1200JD-9 111.79GB

MediaShield Utility Apr 26 2007
