4. The stripe block value is xed and not changeable.
Press [F7] to nish the setting.Press [Y] to clear disk data.
5. The screen displays a MIRROR array of 232.88GB, which is the size of the smallest
hard disk. That is, 232.88GB.
If you want to build a new Operating System (such as Windows XP) in this RAID
system, please press [B] to select it as bootable.
You can then press [Ctrl]+[X] keys to exit the setup program, and restart your PC.
MediaShield Utility Apr 26 2007
- Dene a New Array -
RAID Mode: Mirrored Stripe Block: Optimal
Free Disks Array Disks
Port Disk Model Capacity Port Disk Model Capacity
[-›] Add
[‹-] Del
[ESC] Quit [F6] Back [F7] Finish [TAB] Navigate [↑↓] Select [ENTER] Popup
Mirroring
Optimal
1.0 WDC WD1200JD-9 111.79GB
0.0 WDC WD1200JD-9 111.79GB
2.1 ST3320620AS 298.09GB
1.1 Hitachi HDT725 232.88GB
2.0 HDS728080PLA38 76.69GB
Clear disk data?
[Y] YES [N] NO
MediaShield Utility Apr 26 2007
- Array List -
[Ctrl-X] Exit [↑↓] Select [B] Set Bootable [N] New Array [ENTER] Detail
Boot Status Vendor Array Model Name
No Healthy NVIDIA MIRROR 232.88G
