1
2
1-1 Top View
1-2 Front Side View
1
(190mm)
7.5in
5.3in
(135mm)
No. Name
1 Kensington Lock Attach a Kensington security system or a compatible lock to
secure your Nettop
24mm
1
2
3 6
4
5
No. Name
1 Headphone Port Connects to a headphone
2
Port
Connects to a microphone or playback devices with
optical connectors(3.5mm jack)
3 Multi-Function Card Reader
4 USB 3.0 Ports Connect to USB devices
Caution:Before using it, you need to install the “AS-AS-
5 Suspend Button Enter suspend mode in operating system
6 Power Button with
Turning the power on/off, Indicates system statesIndicates system states
