6.8 Inverter Start-Up
Please refer to the following steps to start up the inverter.
1. Ensure the inverter fixed well on the wall.
2. Make sure all the DC wirings and AC wirings are completed.
3. Make sure the CT/meter is connected well.
4. Make sure the battery is connected well.
5. Make sure the external EPS contactor is connected well (if needed).
6. Turn on the PV/DC switch (for hybrid only), AC breaker, EPS breaker and battery breaker.
7. Enter the settings page, default password is ‘0000’, select START / STOP and set it to start.
Note:
• When starting the inverter for the first time, the country code will be set by default to the local
settings. Please check if the country code is correct.
• Set the time on the inverter using the button or by using the APP.
• The internal bypass relay is closed by default, if it needs to be opened, enter the setting page, select
"Internal".
• EPS function is off by default, if it needs to be opened, enter the setting page, select EPS "ON/OFF",
default eps voltage/frequency is 230V and 50Hz.
6.9 Inverter Switch Off
Please refer to the following steps to switch off the inverter.
1. Enter the settings page, select START / STOP and set it to stop.
2. Turn off the PV/DC switch (for hybrid only), AC breaker, EPS breaker and battery breaker.
3. Wait 5 min before you open the upper lid (if in need of repair).
