1. Notes on This Manual
1.1 Scope of Validity
This manual describes the assembly, installation, commissioning, maintenance and troubleshooting of
the following model(s) of FOXESS products:
H1-3.8-US H1-5.7-US H1-7.6-US H1-9.6-US H1-11.4-US
AC1-3.8-US AC1-5.7-US AC1-7.6-US AC1-9.6-US AC1-11.4-US
Note: Please keep this manual where it will be accessible at all times.
1.2 Target Group
This manual is for qualified electricians. The tasks described in this manual only can be performed by
qualified electricians.
1.3 Symbols Used
The following types of safety instructions and general information appear in this document as described
below:
Danger!
“Danger” indicates a hazardous situation which, if not avoided, will result in death or
serious injury.
Warning!
“Warning” indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
Caution!
“Caution” indicates a hazardous situation which, if not avoided, could result in minor
or moderate injury.
Note!
“Note” provides important tips and guidance.
Table 1-1 Label Description
This section explains the symbols shown on the inverter and on the type label:
Certified to meet the requirements of CSA-C22.2 No. 107.1-16, UL Std.
No. 1741-Third Edition, UL 1741 SB, IEEE 1547-2018, IEEE
1547.1-2020, and CA Rule 21.
Beware of burning.
The case temperature may exceed 140°F (60℃) during operation. Avoid
contact during operation.
Danger of high voltages.
Disconnect from the grid and the PV generator before opening the device.
