1. Fiberglass antenna
2. Signal display screen
Display signal strength, frequency, bandwidth, etc.
Five LED lights stands for Power, Connection and Signal Strength
3. Battery Base
SONY XXXX Battery is acceptable. Exterior power supply is preferred if an exterior
power supply is connected via interface No. 4.
4. Aviation plug
Base End
The aviation plug contains Ethernet, serial port, SBus, power, etc. and the specific
definition is as follow:
VDC-22 / VDC-55 User Manual
©2022 FOXTECH All Rights Reserved 7
