Specification
Wireless
Performance
Bandwidth
800MHz / 1.4GHz / 2.4GHz
Working
Bandwidth
800MHz
:
806MHz
～
825MHz
1.4GHz
:
1427MHz
～
1447MHz
2.4GHz
:
2408MHz
～
2488MHz
Channel
Bandwidth
5MHz/10MHz/20MHz
Modulation Mode
OFDM
Output Power
MK22：30dBm±1dB
MK55：33dBm±1dB
Sensitivity
≤-95dBm
Transmission
Distance
MK22：22km
MK55：55km
Speed In The Air
30Mbps@20MHz
Power Input
DC 9~28V
Power
Consumption
Interface
Antenna
2*SMA, 1*N
Power
1*XT30 Input Power
Serial Port
Air Unit: 2*UART1 RS232; UART2
TTL 3.3V level
Ground Unit: 2*UART1; UART2
RS232
≤8.5W
VDC-22 / VDC-55 User Manual
©2022 FOXTECH All Rights Reserved 11
