ASSEMBLY INSTRUCTIONS
Customer Service: 1800-914-9835 | support@frameitall.com
STEP 3:
Take the entire assembled top frame and insert on
top of the 3 vertical poles. If you are placing this into
an already built raised garden utilize the stake cover
hole and slide the vertical poles through the
stake cover into the stake (see STEP 4 Image)
2
STEP 3
1
2
STEP 4:
Open the green net completely. Use cable ties to
affix the net onto the frame, making sure to equally
space the cable ties along the tubes. Start at the top
affixing 5 ties to each of the horizontal tubes and
then affixing 6 ties to each of vertical tubes.
STEP 4
Garden
Raised Bed
OPTIONAL
To attach a second
veggie wall to the same
garden bed, attach a
cap, one L-connector
to a T-connector as
show in the diagram on
the right. When you do
this, one vertical tube is
not needed.
4
5
12
4
5
6
