INSTALLATION INSTRUCTIONS - FRE90M10B
Plumbers, please ensure a copy of the installation instructions
is left with the end user for future reference
FRANKE
DESIGNER 10 FUNCTION OVEN 90CM
Connecting the supply cable to the mains
Ins
tall a standardized plug corresponding to the load indicated on the data plate. When connecting the cable directly to the
m
ains, install an omni polar circuit breaker with a minimum contact opening of 3 mm between the appliance and the
mains.The omni polar circuit breaker should be sized according to the load and should comply with current regulations (the
earth wire should not be interrupted by the circuit breaker).
The supply cable should be positioned so that it does not reach a temperature of more than 50℃ with respect to the room
temperature, anywhere along its length, or protected by insulation sleeping having an appropriate rating.
Before making the connection, check that:
– The electrical safety of this appliance can only be guaranteed if the cooker is correctly and efficiently earthed, in compliance
with regulations on electrical safety. Always ensure that the earthing is efficient; if you have any doubts call in a qualified
technician to check the system. The manufacturer declines all responsibility for damage resulting from a sys
tem which has not
been earthed.
– Before plugging the appliance into the mains, check that the specifications indicated on the date plate (on the appliance and /
or packaging )correspond to those of the electrical mains system of your home.
– Check that the electrical capacity of the system and sockets will support the maximum power of the appliance, as indicated
on the data plate. If you have any doubts, call in a qualified technician.
– If the socket and appliance plug are not compatible, have the socket replaced with a suitable model by a qualified technician.
The latter, in particular, will also have to ensure that the cross section of the socket cables are suitable for the power absorbed
by the appliance. The use of adapters, multiple sockets and /or extensions, is not recommended. If their use cannot be
avoided, remember to use only single or multiple adapters and extensions which comply with current safety regulations. In
these cases, never exceed the maximum current capacity indicated on the single adapter or extension and the maximum
power indicated on the multiple adapter .The plug and socket must be easily accessible.
Voltage and Frequency of Power Supply
220-240V ~50/60Hz or 50Hz
Model F948-100STMR,F948-101STIX F948-102STIX
Power Source 220-240V ~50/60Hz
Volume (usable capacity) 105 L
Output Power 3,166-3,660 W
Weight Net
Shipping
51kg approx
58.5 kg approx
Dimensions (W x H x D)
Outside
Inner
Cutout
900 x 480 x 560.5mm
657 x 435 x 351mm
867 x 470 x 550mm
TECHNICAL SPECIFICATIONS - FRE90M10B
Meaning of crossed –out wheeled dustbin:
Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities.
Contact you local government for information regarding the coll
ection systems available.
If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into
the food chain, damaging your health and well-being.
When replacing old appliances with new ones, the retailer is legally obligated to take back your old appliance for disposals at
least free of charge.
page 3 of 3
