Franke FM850 - Add-on Unit Technical Data; Refrigeration Unit Specs; Cup Warmer Specs; Flavour Station Specs

min 50
min 200
Installation and technical data
Page 17
40 mm 520 mm + 40 mm = 560 mm
70 mm 520 mm + 70 mm = 590 mm
100 mm 520 mm + 100 mm = 620 mm
Capacity Up to 3 varieties of syrup
Electrical connection 100–240 V1L N PE75 W50/60 Hz Fuse: 10 A
Electrical cable 2000 mm
Weight 20.4 kg
Width 200 mm
Depth 456mm
Height 553 mm
Adjustable feet (optional)
Technical data for the Flavour Station (optional)
Capacity Up to 120 cups (depending on cup size)
Electrical connection 200–240 V1L N PE300 W50/60 Hz Fuse: 10 A
Electrical cable 2000 mm
Weight 17 kg
Width 300 mm
Depth 580 mm
Height 545 mm
Milk container 10 liters or 2 x 4.5 liters
Electrical connection 200–240 V1L N PE100 W50/60 Hz Fuse: 10 A
Electrical cable 2000 mm
Ambient conditions Humidity: max. 80%
Ambient temperature: 5 – 32 °C
Weight Approx. 24 kg
Width 300 mm
Depth 580 mm
Height 545 mm
Technical data for the cup warmer (optional)
Technical data for the refrigeration unit (optional)
Place the add-on units in line with the machine and at eye level.
Distance to the wall must be at least 50 mm. Clearance above the
machine must be at least 200 mm.
Adjustable feet (optional) can be used to compensate for uneven-
ness or height differences.
If optional add-on units are installed, up to an additional 300 mm
may be required per add-on unit.
Add-on unit installation dimensions
