Franke FTU 3805 XS CYLINDRA E LED0 User Manual

EN
6
6
CHARACTERISTICS
Dimensions
Min.
650mm
Min.
650mm
Components
Ref. Q.ty Product Components
1 1 Hood Canopy complete with: Controls, Light,
Filters
3 1 Suction unit
7 1 PVC Pipe
8 1 Directional Grille
8c 1 Air outlet reducer-plug
9 1 Reduction flange ø 150-120 mm
Ref. Q.ty Installation Components
11 4 Wall plugs ø 10
12a 4 Screws 4.2 x 44.4
12b 2 Screws M3 x 8 Torx
12e 6 Screws 2.9 x 9.5
Q.ty Documentation
1 Instruction Manual
3
11
12a
8c
9
7
12e
8
12b
1
11
12a

Franke FTU 3805 XS CYLINDRA E LED0 Specifications

General

Brand	Franke
Model	FTU 3805 XS CYLINDRA E LED0
Category	Ventilation Hood
Language	English
