PUMPTEC-PLUS Pump Protection System
Installation Information
Features
Technical Specications
Horsepower Rating 1/2 to 5 hp
Operating Voltage 230 VAC*
Operating Frequency 60 Hz
Power Consumption 5 Watts
Operating Termperature Range -15 °F to 140 °F
Over/Under Voltage Trip ±10%
Over/Underload Trip ±25%**
Rapid Cycle Trip 4 starts/min
Trip Response Time 2.5 sec
Automatic Restart Time 1 min to 4hr 15 min
Over/Under Voltage Retry 2 min
Calibration Abort Time 3 min
Calibration Memory 10 years
Contactor Rating 5 hp
s WARNING
!
WARNING
To avoid possible fatal shock, disconnect power at the main power
panel before installing, wiring or servicing Pumptec-Plus.
■ Over/Underload Protection ■ Snapshot Calibration
■ Over/Under Voltage Protection ■ Continuous Calibration Memory
■ Rapid Cycle Detection ■ Works With All Single-phase Motors
■ Fault Indicator Lights ■ Transient Surge Protection
■ Run Indicator Light ■ UL Listed (E104778)
■ 5 hp Contactor ■ Adjustable Automatic Restart Timer
■ Heavy-Duty Terminal Blocks ■ Toll-Free Customer Support (800-348-2420)
s WARNING
!
CAUTION
This product does not replace a motor control box or the need for
motor overload protection. Installation and motor overload protection
should be in accordance with National Electrical Code Article 430 or in
accordance with motor manufacturer’s recommendations.
NOTE: This unit requires calibration before operation. Calibration is described in step 7 of the
installation instructions.
* 220 Volt, 50 Hz for model #5800060500
** Percent of load time of calibration SNAPSHOT
