4. Armrest Width Adjustment:
On each side at the rear of the seat you will nd
a large black knob. By simply loosening this
knob you are able to slide the armrests in or out
to whatever width you desire. Re-tighten the
knobs fully.
Warning: DO NOT drive your scooter with
the arms removed or in the raised position.
5. Armrest Angle Adjustment:
The armrest angle can be adjusted individually
to suit your needs. To make adjustments to the
armrest angle you will need a 13mm box socket
and 6 mm hex socket (not provided).
Lift the arm upwards, you will note the adjusting bolt. First loosen the locking nut, rotate the
bolt in or out until the required angle is found, lower the arm and check the angle for comfort;
re-adjust as necessary.
Finally the tighten locking nut.
6. Seat Height Adjustment:
You may need to alter the seat height setting at
a later date, please follow these instructions.
(1) Remove your seat from the scooter by
lifting the seat.
(2) With the aid of a 16mm wrench (not
supplied) loosen the 10mm seat clamp
fixing bolt from side of seat post.
Remove the 10mm fixing bolt and
reposition the bolt into one of the four
preferred location holes of the seat
mounting tube.
(3) Re-tighten the 10mm xing screw.
(4) Ret the seat onto your scooter.
wrench
8
