OPERATING YOUR SCOOTER
Before setting out on your scooter you need to make sure that your seat is in the
correct driving position. The seat has three basic adjustments to assist your comfort.
1. Mirror Assemble:
2. Seat Lock Lever:
This allows the seat to swivel through 360 degree. Pull up
the seat lock lever fully to release the seat allowing rotation.
Release lever to lock the seat into the desired position.
Caution: The seat locking lever must be locked in place and
be lifted up fully when rotating the seat, failure to observe
this may result in unnecessary wear of the seat post.
Removing seat from Scooter:
Note: When you want to remove the seat you must go
through a special lifting point on the mounting post. This
lifted point is 90 degree counting from the horizontal
direction.
(1) Pull up seat lock lever fully.
(2) In the meantime rotate the seat to 90 degree from
the straight ahead position.(either left or right side)
(3) Lift up and remove the seat carefully.
14mm
wrench
(Seat Lock Lever)
3. Seat Back Adjusted:
(1) Pulling up on the seat back adjustment lever,
lean forward or backward to adjust the seat back.
(2) Release the seat back adjustment lever once the
seat is in a comfortable riding position.
Note: The seat back angle can be adjust to a maximum
angle of 102.8 degree.
7
Mirror Assemble
Seat Lock
Seat Back Adjusted
