10. Technical Specification
10.1 – Dimensions and Weights
Model Specification
(All dimensions in mm and Kg)
Raiser
Maximum weight capacity
160kg
Turning radius
360degree
Overall height
1201 mm
Ground clearance
19.50mm
Front and rear castors
35mm
Wheels
125mm
Weights
Handle
6.5kg
Base assembly
12.5kg
Assembled unit
19kg
10.2 – Raiser dimensions
1201
1149
967
797
19.50
645 dia
175
175
475
465
200
180-330
590
12
