Me-262 Structure Diagram
Me-262结构分解图
Screw PA3*10mm
Screw
PWA3*12mm
Main LandingGear
70mm Ducted Fan
EDF Cabin Cover
Front Landing Gear
EDF Cabin Cover
Fixing Part
Anti-Friction Blister
Screw PWA3*8mm
Screw PA4*15mm
Screw PWA3*12mm
Screw PWA3*12mm
Screw PA3*10mm
Main Wing Fixing Part ( Front)
Main Wing Fixing Part ( Rear)
Rudder Fixing Part
Carbon Tube
L=250mm 10mm
Carbon Tube
L=350mm 10mm
Item No.: F3801
产品 编号:
-1 3-
版本 号:
Version No.: F3801-V01
F3801-V01
Me 262
F3801
R
