Externalbutton, opens/closes folding door
2
Lock cylinder position, unlocked
3
Lock cylinder position, locked
?
Lock cylinder
A
Buttonfor opening/closing folding door
and activating/deactivating externalbut-
ton
Vehicles with hingedco-driver'sdoor:
locks cab doors
B
Internal button, opens/closes folding door
Unlocking/locking
On vehicles with lock cylinders ? it is possi-
bletounlock and lock the folding door from
the outside.
X
To unlock: insert the key into lock cylin-
der ? and turnittoposition 2.
X
To lock: insert the key into lock cylinder ?
and turnittoposition 3.
Activating/deactivating the external but-
ton
It is possibletoactivate/deactivate external
button :.Ifyou deactivate externalbut-
ton :,the folding door cannotbeopened
fromthe outside.
X
Press the lowersectionofbutton A.
When the indicator lamp in button A lights
up,the externalbutton is deactivated.
Unlocking/lockingcab doors
X
To unlock/lock: press the lowersectionof
button A.
When the indicator lamp in button A lights
up,the cab doors arelocked.
Opening/closing the folding door
X
Vehicles with lock cylinders:unlock the door
using the door lock.
X
Turn the key to the radiopositioninthe igni-
tionlock.
X
Press the uppersectionofbutton A.
or
X
Press internalbutton B.
or
X
Press externalbutton :.
The folding door opens or closes.
Youare onlyabletoopenorclose the folding
door at speeds below2mph (3 km/h).
If youpullawaywiththe folding door open, it
will automaticallyclose once aspeed of 2mph
(3 km/h)isreached.
If the obstacle detection detects an obstacle
whilethe folding door is being closed,the fold-
ing door opens againautomatically.
