Evaporator Sensor Resistance Chart
A
B
C
D
1
Evaporator Sensor
2
3
Temp(ºF)
Temp (ºC)
Resistance
(nominal)
Voltage
(nominal)
4
-40.0
-40.0
92757.0
4.554
5
-31.0
-35.0
66870.0
4.402
6
-22.0
-30.0
48790.0
4.215
7
-13.0
-25.0
35937.0
3.991
8
-4.0
-20.0
26757.0
3.732
9
5.0
-15.0
20103.0
3.443
10
14.0
-10.0
15252.0
3.133
11
23.0
-5.0
11664.0
2.81
12
32.0
0.0
9000.0
2.488
13
41.0
5.0
6998.0
2.175
14
50.0
10.0
5485.0
1.882
15
59.0
15.0
4330.0
1.613
16
68.0
20.0
3443.0
1.374
17
77.0
25.0
2757.0
1.164
18
86.0
30.0
2221.0
0.982
19
95.0
35.0
1800.0
0.826
20
104.0
40.0
1468.0
0.695
21
113.0
45.0
1204.0
0.585
22
122.0
50.0
993.2
0.493
23
131.0
55.0
823.2
0.415
24
140.0
60.0
685.8
0.351
25
149.0
65.0
574.2
0.297
26
158.0
70.0
482.9
0.252
27
167.0
75.0
408.3
0.215
28
176.0
80.0
346.8
0.184
29
185.0
85.0
295.6
0.157
