B: Compressor
This unit is part of the hermetically sealed
refrigeration system.
C: Thermal Limit Switch on Compressor
This is a normally closed switch to protect
compressor from high temperature.
D: Evaporator Blower
This blower pulls air through the evaporator
coil to cool the interior of the sleeper.
Units built with RING TERMINAL compressor.
Follow instructions on pages 38-41 for Harness
and Controller Service. New 10-2015
