9
Park Smart System Diagnostic Table
TRUCK MUST BE IN PARKED MODE TO PERFORM
DIAGNOSTIC TESTS!
For additional wiring diagrams and J1939 fault codes see Freightliner doc
# C02.03
PROBLEM
CORRECTIVE ACTION / SEE APPENDIX
Unit Will Not Run or Turn
On
1. Confirm all connections are tight, including ground lugs,
and terminals crimped on wires and battery cables.
2. Check AUX batteries for voltage. Low voltage cut out
11.3
3. Remove F6 programming fuse and cycle power off to
reset.
4. Check F2 fuse for continuity and/or voltage and 12 volt
input at pin C1 on Control PCB Assembly. See appendix
F.
5. Check for 12 volts and ground at AUX control panel.
See appendix C
6. Check Wake up signal pin D6 on Control PCB
Assembly. See appendix C and /or I.
7. Test Control PCB Assembly. See appendix I
8. Truck parked 0 volts to pin C4. Brakes released 12 volt
to pin C4. Check for input. See Appendix I
9. Check unfused 12 volt power signal from Aux batteries
to C3. See appendix I
10. Inspect all wiring and harness connections.
11. Check for loss of communication on Can Bus J1939.
Check for loss of wake up signal (switched to ground)
from control to pin D6 on Control PCB Assembly. See
appendix C
Unit runs in parked mode
but not engine running
mode.
1. Inspect all wiring and harness connections.
2. Check connections and test both relays. See appendix D
3. Check fuse. See appendix F
4. Determine if ground from Control PCB Assembly has
failed. See appendix I
Unit runs in Engine On
mode, but not Engine Off
1. Check Aux batteries and battery separator. See
Appendix A & B
2. Park brake switch defective, wiring harness issue or
wrong switch logics
3. Loss of wake up signal. Check Aux control panel and
control PCB Assy. See Appendix C & I.
4. Check relays and wiring. See Appendix D
5. Check wiring harness connectors and physical condition.
6. Check for Aux battery voltage (12V) at the control PCB
Assy pin C3.
