Sleeper & Ambient Air Sensor Resistance Chart
A
B
C
D
1
Sleeper, Condenser Air Inlet Temperature Sensor
2
3
Temp(ºF)
Temp (ºC)
Resistance
(nominal)
Voltage
(nominal)
4
-40.0
-40.0
336500.0
4.86
5
-31.0
-35.0
242589.0
4.80
6
-22.0
-30.0
177000.0
4.73
7
-13.0
-25.0
130370.0
4.64
8
-4.0
-20.0
97070.0
4.53
9
5.0
-15.0
72929.0
4.40
10
14.0
-10.0
55330.0
4.24
11
23.0
-5.0
42315.0
4.04
12
32.0
0.0
32650.0
3.83
13
41.0
5.0
25388.0
3.59
14
50.0
10.0
19900.0
3.33
15
59.0
15.0
15708.0
3.06
16
68.0
20.0
12490.0
2.78
17
77.0
25.0
10000.0
2.50
18
86.0
30.0
8057.0
2.23
19
95.0
35.0
6531.0
1.98
20
104.0
40.0
5327.0
1.74
21
113.0
45.0
4369.0
1.52
22
122.0
50.0
3603.0
1.32
23
131.0
55.0
2986.0
1.15
24
140.0
60.0
2488.0
1.00
25
149.0
65.0
2083.0
0.86
26
158.0
70.0
1752.0
0.75
27
167.0
75.0
1481.0
0.65
28
176.0
80.0
1258.0
0.56
