WARNING: To avoid potential property damage or personal
injury, Read Important Safety Warnings and ALL instructions before
attempting to install or service product.
CAUTION: Care must always be taken to install the control cover without
bending the connector pins identified in FIGURE 1.
34
Service Instructions for Phase Harness / Ring Terminal Compressor Only
Harness routing
for ring terminal
