QUANTUM
™
LX EVAPORATOR CONTROL PANEL
MAINTENANCE
090.610-M (MAY 2016)
Page 60
QUANTUM™ LX EVAPORATOR REPLACEMENT PARTS (Page 1 of 2)
Evaporator Q5 Operator Interface Panel
Frick Number SAP Number Description
Circuit Breakers
639A0206H05 484047 5 Amp circuit breaker
Control Power
639A0185H10 483963 2-Pos. Selector Switch (Control Power)
639A0185H30 483966 Latch, 3 Across (Attaches contact block to switch mechanism)
Display
639A0261H01 484329 CCFT inverter
639B0117H01 670741 Display Harness
639C0132H01 484379 Display
639C0143H01 670593 Mounting plate (for Display, CPU and Interface board)
640A0032H02 569676 Plexiglas Fill-piece for display
639A0278H01 548266 Display adapter board (Bat wing)
639B0104H01 552141 Inverter cable
Flash Cards and Software
649A1112Gxx 901354 Program Flash Card (the xx indicates program version)
649A1063G99 485995 Quantum™ LX Setpoint Saver (USB Drive)
Harnesses
639D0218H01 850941 DC power and communications harness
639D0191H02 696514 Keypad and Communications cable kit
Keypads
640D0186H01 484621 Keypad/overlay with Frick
®
logo (Quantum™ LX)
Power Supplies
639B0115H02 642308 12 VDC power supply
Quantum™ Controllers
639C0141G01 686440 Q5 Board (Advantage)
639B0116H01 677556 Q5 Interface Communications Board
