QUANTUM™ LX EVAPORATOR REPLACEMENT PARTS (Page 2 of 2)
Evaporator Remote Panels
Part Number Description
Analog Board
640C0057G01 Analog Board #1 (Replaces existing 32 channel board #1 only - no hardware)
640C0057G33 Analog Board #1 (Field Upgrade Kit – Includes 32 channel board #1, connectors & hardware.)
Circuit Breakers (for optional panel heater)
639A0206H03 3 Amp circuit breaker
Digital Boards
111Q0281061 Output Module, 24-280 volt AC
333Q0000116 Input Module, 120 volt AC
333Q0001326 Fuse, 5 amp, 250 V
640C0024G31 Digital Board #1 (Replaces existing board)
640C0024G32 Digital Board #2 (Replaces existing board)
Harnesses
639C0124H01 DC power
640B0059H01 AC power
649B0931H01 DC power and communications harness
649D5579H01 AC power and I/O
649D5622H01 AC I/O harness, 2nd Digital board
640B0039H01 Shunting plug (for troubleshooting only)
Panel Heater (Optional)
333Q0001179 Heater, ex, 120 VAC, 150 W
Power Supplies
640B0060H01 DC Power Supply
639A0262H01 5 VDC Power Supply
639A0262H02 12 VDC Power Supply
639A0262H03 24 VDC Power Supply
HOA Modules
639C0123H01 HOA Assembly, Complete DIN Rail Mounted
649B0776H01 HOA Module (no labels)
333Q0001738 HOA Fuse, 2 Amp
