RXF PLUS MICROPROCESSOR CONTROL PANELS70-401 IOM
Page 18
RETURN FULL LOAD AMPS COMMAND: #IDA
# Start command sequence.
ID Compressor ID code.
A Return full load amps command.
If the command was #01A, then the micro-
processor would dump the full load amps value.
RETURNED ANSWER:
XXX = 3 characters followed by a carriage
return, line feed.
COMPRESSOR DISPLAY SCREENS COMMAND: #IDDX
# Start command sequence.
ID Compressor ID code.
D Compressor control command.
X = O Operating displays (7 pages, 308 chars)
X = S Adjustable Setpoints displays
(10 pages, 440 characters)
X = X Fixed Setpoints displays (4 pages, 176 chars)
X = C Autocycle displays (3 pages, 132 chars)
X = B Setback displays (3 pages, 132 chars)
X = P Security display (1 page, 44 chars)
X = + Analog Offset displays (4 pages, 176 chars)
X = F Freeze displays (7 pages, 308 chars)
X = R Shutdown Record displays (6 pages, 264 chars)
If the command was #01D0, then the micropro-
cessor would dump the operating display.
CHANGE SETPOINTS COMMAND: #IDC
# Start command sequence.
ID Compressor ID code.
C Change setpoint command.
xxx New setpoint
xx New setpoint
y g or h for gauge or inches
The following is the complete list of the
setpoints that may be changed while in the
change setpoints command:
01xxxy Capacity Control (pressure)
02xxxy Change Low Pressure Cutout
03xxxy Change Low Pressure Alarm
04xxx Change High Pressure Cutout
05xxx Change High Pressure Alarm
06xxx Change MLC Stop Load
07xxx Change MLC Force Unload
08xx Change Recycle Delay
09xxx Change CTF
10xx Proportional Band (pressure)
11xx Dead Band (pressure)
12xx Cycle Time (pressure)
13+xxx Capacity Control (temperature)
14+xxx Low Temp Cutout (temperature)
15+xxx Low Temp Alarm (temperature)
16xx Proportional Band (temperature)
17xx Dead Band (temperature)
18xx Cycle Time (temperature)
19x Cap Control (temp/press mode switch)
01 Compressor ID code.
RETURNED ANSWER:
Axxxx The new setpoint which was sent
followed by a carriage return, line
feed.
If the command was sent #01C01300g01, the
capacity control setpoint would be changed
to 30.0g and the returned answer is A300g
followed by a carriage return, line feed.
If the command sent was #01C0711001, the MLC
force unload setpoint would be changed to
110% and the returned answer is A110 fol-
lowed by a carriage return, line feed.
If the command sent was #01C0520002, the
returned answer is BAD followed by the ID
number and a carriage return, line feed.
READ FAILURES COMMAND: #IDF
# Start command sequence.
ID Compressor ID Code.
F Read Failures command.
Returned Answer:
0000000000000000000000000000000000000000000
Character Description
Position
1 High Press Cutout
2 High Press Alarm
3 Low Press Cutout
4 Low Press Alarm
5 Oil Press Cutout
6 Oil Press Alarm
7 Hi Oil Temp Cutout
8 Hi Oil Temp Alarm
9 Lo Oil Temp Cutout
10 Lo Oil Temp Alarm
11 Disch Temp Cutout
12 Disch Temp Alarm
13 Comp Auxiliary
14 Pump Auxiliary
15 Oil Level
16 Comp Differential
17 Low Temp Cutout
18 Low Temp Alarm
19 Aux. #1 Alarm
20 Aux. #1 Shutdown
21 Superheat Alarm
22 Superheat Cutout
23 Sep. Cond. Alarm
24 Sep. Cond. Cutout
25 Aux. #2 Alarm
26 Aux. #2 Shutdown
27 Sensor Low Sep Temp
28 Sensor High Sep Temp
29 Sensor Lo Disch Temp
30 Sensor Hi Disch Temp
31 Sensor Low Oil Temp
32 Sensor High Oil Temp
33 Sensor Low Oil Press
34 Sensor Hi Oil Press
35 Sensor Lo Suct Press
36 Future
37 Sensor Lo Disch Press
38 Sensor Hi Disch Press
39 Low Motor Amps
40 Future
41 Future
42 Future
43 Factory Defaults Set
Example:
If the answer returned was
000000000000000000000000000000000000000000033,
compressor #2 has an Oil Press Alarm.
READ PROCESS TEMPERATURE COMMAND #IDTT
# Start command sequence
ID Compressor ID Code
TT Return process temperature command
RETURNED ANSWER:
XXX = 3 characters followed by a carriage
return, line feed.
OPERATION
g or h
: must be lower case - exception to "All commands
must be caps" statement at beginning of section.
