RXF PLUS MICROPROCESSOR CONTROL PANEL S70-401 IOM
Page 7
play. The applicable failure displays will be individually ro-
tated through by pressing the [STEP] key. Continued press-
ing of the [STEP] key will result in the applicable failure dis-
plays repeating.
At this time the alarm will stop flashing. Pressing the
[CLEAR] key while at the Annunciator display will clear all
alarms and/or cutouts.
In order to restore the Annunciator display and resume nor-
mal operation, it will be necessary to go through the follow-
ing steps:
1. Correct the conditions causing the alarm.
2. Press the [ALARM SILENCE] key. (This action may pre-
cede correcting the conditions causing the alarm).
3. To clear or reset the Annunciator pages, press the
[CLEAR] key. This will also clear the ALARM, SHUTD, or
CUTOUT indicator from the Operating display.
4. Press [F1] to call up the Operating display. If the condi-
tions causing the alarm have not been corrected or a new
fault has occurred, the ALARM, SHUTD, or CUTOUT mes-
sage will appear.
NOTE: Use of the Emergency Stop Button may trip one
or more alarm setpoints.
5. After all failures have been corrected and the [CLEAR]
key has been pressed and if there are no failures, the An-
nunciator display will show (NO FAILURES).
ANNUNCIATOR DISPLAY, NO FAILURES*
ANNUNCIATOR
NO FAILURES
ANNUNCIATOR DISPLAY, 1 FAILURE*
ANNUNCIATOR
HIGH PRESS CUTOUT
ANNUNCIATOR DISPLAY,
MULTIPLE FAILURES*
ANNUNCIATOR USE STEP
HIGH PRESS ALARM
The remaining screens show additional
failure messages that may appear.
ANNUNCIATOR DISPLAY*
ANNUNCIATOR
LOW PRESS CUTOUT
ANNUNCIATOR DISPLAY*
ANNUNCIATOR USE STEP
LOW PRESS ALARM
* Display for illustrative purposes only.
OPERATION
ANNUNCIATOR DISPLAY*
ANNUNCIATOR
OIL PRESSURE CUTOUT
ANNUNCIATOR DISPLAY*
ANNUNCIATOR
OIL PRESS ALARM
ANNUNCIATOR DISPLAY*
ANNUNCIATOR
HI OIL TEMP CUTOUT
ANNUNCIATOR DISPLAY*
ANNUNCIATOR
HI OIL TEMP ALARM
ANNUNCIATOR DISPLAY*
ANNUNCIATOR
LO OIL TEMP CUTOUT
ANNUNCIATOR DISPLAY*
ANNUNCIATOR
LO OIL TEMP ALARM
ANNUNCIATOR DISPLAY*
ANNUNCIATOR
DISCH TEMP CUTOUT
ANNUNCIATOR DISPLAY*
ANNUNCIATOR
DISCH TEMP ALARM
ANNUNCIATOR DISPLAY*
ANNUNCIATOR
COMPRESSOR AUXILIARY
ANNUNCIATOR DISPLAY*
ANNUNCIATOR
PUMP AUXILIARY
ANNUNCIATOR DISPLAY*
ANNUNCIATOR
OIL LEVEL
ANNUNCIATOR DISPLAY*
ANNUNCIATOR
COMP DIFFERENTIAL
