ELECTRICAL CONNECTIONS
THIS APPLIANCE MUST BE EARTHED.
insert the discarded plug into a socket.
Fitting a new plug
If for any reason you need to a new plug, the mains lead must be
connected as shown here.
accordance with the following code:
10
If the colours of the wires in the mains lead of this appliance do not
correspond with the coloured markings identifying the terminals in your
plug, proceed as follows:
The wire which is coloured Green and Yellow MUST be connected to the
terminal which is marked with the letter E (Earth) or symbol or
coloured Green. The wire which is coloured Blue MUST be connected to
the terminal which is marked with the letter N or coloured Black. The
wire which is coloured Brown MUST be connected to the terminal which
is marked with the letter L or coloured Red.
strands of wire inside the plug.
Use a 13 Amp BS1362 fuse, only BSI or ASTA approved fuses should be
used. If you are in any way unsure which plug or fuse to use, always refer
Note: After replacing or changing a fuse on a moulded plug which has a
be used without a fuse cover. If lost, replacement fuse covers can be
obtained from an electrical shop
.
This appliance complies with the following EEC Directives:
73 / 23 EEC (Low Voltage Directive)
89 / 336 EEC (EMC Directive).
CONNECT GREEN AND
YELLOW TO EARTH (E)
CONNECT
BLUE TO
NEUTRAL (N)
MAKE SURE THE OUTER
SHEATH OF THE MAINS
LEAD IS SECURELY HELD BY
THE CLAMP
CONNECT
BROWN TO
LIVE (L)
13 AMP FUSE
