Friedrich 2006 - Small Chassis S Series Parts List - 115 V

11
SMALL CHASSIS "S" SERIES PARTS LIST - 115V
* PARTS NOT SHOWN
SMALL CHASSIS 115 VOLT - 2006
REF DESCRIPTION PART NO# RS 115 SS 115 YS 115 CODE
ELECTRICAL PARTS
KS10L10-A
KS12L10-B
KS15L10-A RS10L10-A
RS12L10-B
RS15L10-A
SS08L10-B SS09L10-D SS10L10-B SS12L10-C SS14L10-B YS09L10-C
1 THERMOSTAT 61822500 111111 120
1 THERMOSTAT 61822400 1 120
* THERMOSTAT, DEFROST 61350313 1 122
2 ELECTRONIC CTRL. 61921173 1 1 1 1 1 331
* REMOTE CONTROL 61826605 1 1 1 1 1 350
3 RESISTOR 61808000 111111 1 200
* OVERLOAD 61764519 11 11 111 1 190
* OVERLOAD 61764544 1 1 1 190
* OVERLOAD 61764507 1 190
4 CAPACITOR 61080535 1 1 1 150
4 CAPACITOR 61080554 1 1 1 150
4 CAPACITOR 61080569 11 11 11 150
5 SUPPLY CORD 60500110 1 220
5 SUPPLY CORD 60500304 1 11111 1220
5 SUPPLY CORD 60500305 1 1 1 1 220
6 SWITCH SYS. 6 POS. 60607205 111111 130
6 SWITCH SYS. 8 POS. 60607204 1 130
7 SWITCH (YES - NO) 61806102 111111 1 132
8 FAN MOTOR 61871444 11111111111 1 110
* SOLENOID COIL 25063500 1 240
REF DESCRIPTION PART NO# RS 115 SS 115 YS 115 CODE
REFRIGERATION PARTS
KS10L10-A
KS12L10-B
KS15L10-A RS10L10-A
RS12L10-B
RS15L10-A
SS08L10-B SS09L10-D SS10L10-B SS12L10-C SS14L10-B YS09L10-C
9 COMPRESSOR 61716641 1 1 1 600
9 COMPRESSOR 61716671 1 1 1 600
9 COMPRESSOR 61716653 1 1 1 600
9 COMPRESSOR 61562832 1 600
9 COMPRESSOR 61716665 1 1 600
10 EVAPORATOR COIL 62050014 1 1 1 1 1 400
10 EVAPORATOR COIL 61850101 1 1 400
10 EVAPORATOR COIL 61850100 1 1 1 1 1 400
11 CONDENSER COIL 61850303 1 1 410
11 CONDENSER COIL 61850217 1 410
11 CONDENSER COIL 61850302 1 1 1 1 410
11 CONDENSER COIL 62050317 1 1 410
11 CONDENSER COIL 62050302 1 1 1 410
* DRIER, LIQUID 60308101 11111111111 480
* DRIER, SUCTION 61828200 1 480
* CHECK VALVE 61824400 1 510
* REVERSING VALVE 25018201 1 500
* CAPILLARY TUBE 03760518 1 471
* CAPILLARY TUBE 03760520 1 1 1 471
* CAPILLARY TUBE 03760473 1 1 1 471
* CAPILLARY TUBE 03760548 1 471
* CAPILLARY TUBE 03760501 1 1 1 471
* CAPILLARY TUBE 03760452 1 471
* CAPILLARY TUBE 03760556 1 471
