SMALL CHASSIS "S" SERIES PARTS LIST - 115V
* PARTS NOT SHOWN
SMALL CHASSIS 115 VOLT - 2006
REF DESCRIPTION PART NO# RS 115 SS 115 YS 115 CODE
CHASSIS PARTS
KS10L10-A
KS12L10-B
KS15L10-A RS10L10-A
RS12L10-B
RS15L10-A
SS08L10-B SS09L10-D SS10L10-B SS12L10-B SS14L10-B YS06L10-C
12 SHROUD, SML W/SUMP LOOP 61803601 11111111111 1 720
13 FAN BLADE, CONDENSER 60542003 11111111111 1 710
14 BLOWER WHEEL, EVAPORATOR 60610603 1 1 1 1 1 1 700
14 BLOWER WHEEL, EVAPORATOR 60610604 111111700
15 BRACE, COND. SHROUD 61802600 33333333333 3 722
16 SCROLL 61814905 11111111111 1 743
17 BLOWER FRONT 61817300 11111111111 1 742
* INSULATION, INNER WALL 61816900 11111111111 1 781
18 INNER WALL 61907300 11111111111 1 777
19 COVER, TOP 61906700 11111111111 1 746
20 INSULATION, TOP COVER 61816701 11111111111 1 781
21 DECK 61817100 11111111111 1 745
22 AIR FOIL 61820200 11111111111 1 744
23 MOUNT, FAN MOTOR 61802500 11111111111 1 900
27 BASE PAN 61803409 1 1 730
27 BASE PAN 61803411 111111 111 730
27 BASE PAN 61809003 1 730
* DRAIN PAN 61803800 11111111111 1 840
* BELLOWS, DRAIN VALVE 60179903 1 801
* GRILLE, REAR 61818500 11111111111 1 771
28 DOOR, SLIDE ASSLY. 61821500 11111111111 1 810
* CONNECTOR, SLIDE DOOR 61814800 1111111111 1 811
29 PANEL, CTRL. MT. 61807250 111111 1 999
29 PANEL, CTRL. MT. 61807251 11111 999
30 BRACKET, CAP. MT 61820400 11111111111 1 999
* PANEL, L/S 61937200 11111111111 1 999
31 PARTITION, CTRL. BOX 61802800 11111111111 1 999
32 DECORATIVE PANEL 61822603 1 1 1 999
32 DECORATIVE PANEL 61823350 1 999
32 DECORATIVE PANEL 61822654 1 1 1 999
33 KNOBS, CTRL. 61493905 222222 2 761
* HOLDER, THERMISTER 61925001 11111 764
* HOLDER, AIR FILTER 60865900 22222222222 2 756
* FILTER, AIR 60865808
11111111111 1 754
* CLAMP, SUPPLY CORD 91500305 11111111111 1 999
* BRACKET, RESISTO BLOCK 61820600 111111 1 999
34 GROMMET, COMPRESSOR 61028900 33333333333 3 790
35 SCREW, COMPRESSOR MT. 91400400 33333333333 3 999
* COUNTER WEIGHT 61715800 33333333333 3 999
36 PLENUM ASSLY. 61810205 11111111111 1 753
