Friedrich 2006 - Small Chassis S Series Parts List - 230 V

14
* PARTS NOT SHOWN
SMALL CHASSIS "S" SERIES PARTS LIST - 230V
SMALL CHASSIS 208/230 VOLT - 2006
REF DESCRIPTION PART NO# ES 230 KS 230 RS 230 SS 230 YS 230 CODE
ELECTRICAL PARTS
ES12L33-A ES16L33-A
KS12L30-A RS16L30-A
SS12L30-B SS16L30-B
YS13L33-A
1 THERMOSTAT 61822400 1 1 1 120
1 THERMOSTAT 61822500 1 1 120
* RESISTOR 61808001 1 1 1 1 1 200
* THERMOSTAT, DEFROST 61350313 1 122
REMOTE CONTROL 61826605 1 1 399
2 ELECTRONIC CTR. 61921174 1 1 331
* OVERLOAD 61764521 1 1 190
* OVERLOAD 61764556 1 1 1 190
* OVERLOAD 61764540 1 1 190
4 CAPACITOR 61080534 1 1 1 150
4 CAPACITOR 61080536 1 1 1 1 150
5 SUPPLY CORD 60500103 1 1 1 220
5 SUPPLY CORD 60500102 1 1 1 1 220
6 SWITCH, SYS. 8 POS. 60607204 1 1 1 130
6 SWITCH , SYS. 6 POS 60607205 1 1 130
7 SWITCH (YES - NO) 61806102 1 1 1 1 1 132
8 FAN MOTOR 61871441 11 1 1111110
* SOLENOID 25063600 1 240
8A HEATER 61878600 1 1 1 210
* FUSE LINK 61596301 1 1 1 192
* LIMITER, HEATER 61827901 1 1 1 193
REF DESCRIPTION PART NO# ES 230 KS 230 RS 230 SS 230 YS 230 CODE
REFRIGERATION PARTS
ES12L33-A ES16L33-A
KS12L30-A RS16L30-A
SS12L30-B SS16L30-B
YS13L33-A
9 COMPRESSOR 61716628 1 1 600
9 COMPRESSOR 61716645 1 1 600
9 COMPRESSOR 62199704 1 1 1 600
10 EVAPORATOR COIL 61850100 1 1 1 400
10 EVAPORATOR COIL 61850101 1 400
10 EVAPORATOR COIL 62050014 1 1 1 400
11 CONDENSER COIL 61850217 1 410
11 CONDENSER COIL 61850302 1 1 410
11 CONDENSER COIL 61850306 1 410
11 CONDENSER COIL 62050302 1 1 1 410
* DRIER, LIQUID 60308101 1 1 1 1 1 1 480
* DRIER, SUCTION 61828200 1 480
* CHECK VALVE 61824400 1 510
* REVERSING VALVE 25018301 1 500
* CAPILLARY TUBE 03760543 1 471
* CAPILLARY TUBE 03760545 1 471
* CAPILLARY TUBE 03760473 1 1 471
* CAPILLARY TUBE 01390005 1 1 1 471
* CAPILLARY TUBE 03760520 1 471
