SMALL CHASSIS "S" SERIES PARTS LIST - 230V
* PARTS NOT SHOWN
SMALL CHASSIS 208/230 VOLT - 2006
REF DESCRIPTION PART NO# ES 230 KS 230 RS 230 SS 230 YS 230 CODE
CHASSIS PARTS
ES12L33-A ES16L33-A
KS12L30-A RS16L30-A
SS12L30-B SS16L30-B
YS13L33-A
12 SHROUD, CONDENSER 61803601 1 1 1 1 1 1 1 720
13 FAN BLADE 60542003 1 1 1 1 1 1 1 710
14 BLOWER WHEEL 60610603 1 1 700
14 BLOWER WHEEL 60610616 1 1 1 1 1 700
15 BRACE, COND. SHROUD 61802600 3 3 3 3 3 3 3 722
16 SCROLL 61814905 1 1 1 1 1 1 1 743
17 BLOWER FRONT 61817300 1 1 1 1 1 1 1 742
19 COVER, TOP 61906700 1 1 1 1 1 1 1 746
21 DECK 61817100 1 1 1 1 1 1 1 745
23 MOUNT, FAN MOTOR 61802500 1 1 1 1 1 1 1 900
25 BRACKET, HEATER MT. 61818900 1 1 1 999
27 BASE PAN 61809005 1 1 730
27 BASE PAN 61803411 1 1 1 1 730
27 BASE PAN 61809001 1 730
* DRAIN PAN 61803800 1 1 1 1 1 1 1 840
* BELLOWS, DRAIN VALVE 60179903 1 1 1 801
* GRILLE, REAR 61818800 1 1 1 1 1 1 1 771
28 DOOR, SLIDE ASSLY. 61821500 1 1 1 1 1 1 1 810
* CONNECTOR, SLIDE DOOR 61814800 11 1 1111811
29 PANEL, CTRL. MT. 61807251 1 1 999
29 PANEL, CTRL. MT. 61807250 1 1 1 1 1 999
30 BRACKET, CAP. MT 61820400 1 1 1 1 1 1 1 999
* PANEL, L\S 61937200 1 1 1 1 1 1 1 999
31 PARTITION, CTRL. BOX 61802800 1 1 1 1 999
31 PARTITION, CTRL. BOX 61802801 1 1 1 999
32 DECORATIVE PANEL 61823300 1 1 1 999
32 DECORATIVE PANEL 61822603 1 999
32 DECORATIVE PANEL 61822600 1 999
33 KNOBS, CTRL. 61493905 2 2 2 2 2 761
29 PANEL, CONTROL SML 61807200 1 1 1 1 1 999
29 PANEL, CONTROL 61807201 1 1 999
* HOLDER, THERMISTER 61925001 1 1 764
* HOLDER, AIR FILTER 60865900 2 2 2 2 2 2 2 756
* FILTER, AIR 60865808 1 1 1 1 1 1 1 754
* CLAMP, SUPPLY CORD 91500306 1 1 1 1 1 1 1 999
* BRACKET, RESISTO BLOCK 61820600 1 1 1 1 1 999
34 GROMMET, COMPRESSOR 61028900 3 3 3 3 3 3 3 790
35 SCREW, COMPRESSOR MT. 91400400 3 3 3 3 3 3 3 999
36 PLENUM ASSLY. 61810205 1 1 1 1 1 1 1 753
* KNOB, FRESH AIR & EXHAUST 61809300 1 1 1 1 1 1 1 761
