Friedrich 2006 - Large Chassis L Series Parts List

24
LARGE CHASSIS "L" SERIES PARTS LIST
* PARTS NOT SHOWN
LARGE CHASSIS 208.230 VOLT - 2006
REF DESCRIPTION PART NO# SL 230 EL 230 CODE
ELECTRICAL PARTS
SL25L30-B
SL28L30-A
SL36L30A-A
EL25L35-B
EL36L35A-A
YL24L35-A
1 THERMOSTAT 61828500 1 1 120
1 THERMOSTAT 61822400 1 120
1 THERMOSTAT 61822500 1 120
1 THERMOSTAT 61828400 1 1 120
* THERMOSTAT, DEF. 61350313 1 122
4 CAPACITOR 61080529 1 1 1 150
4 CAPACITOR 61080557 1 150
4 CAPACITOR 45/2.0 440 61080527 1 1 150
4 CAPACITOR 61080564 150
5 SUPPLY CORD 60500103 1 1 220
5 SUPPLY CORD 60500141 1111 220
3 RESISTOR 61808001 111111 200
6 SWITCH SYS. 5 POS. 60607203 1 1 1 130
6 SWITCH SYS. 8 POS. 60607204 1 1 1 130
7 SWITCH (YES - NO) 61806102 111111 132
8 FAN MOTOR 61871446 11 110
8 FAN MOTOR 61871467 11 1 1 110
8 FAN MOTOR 61871434 110
* SOLENOID COIL 25063600 1 240
8A HEATER 61878612 1 1 1 210
REF DESCRIPTION PART NO# SL 230 EL 230 CODE
REFRIGERATION PARTS
SL25L30-B
SL28L30-A
SL36L30A-A
EL25L35-B
EL36L35A-A
YL24L35-A
9 COMPRESSOR 61716652 1 1 1 600
9 COMPRESSOR 61716650 1 600
9 COMPRESSOR 61716669 1 1 600
10 EVAPORATOR COIL 62050001 1 1 1 400
10 EVAPORATOR COIL 61850003 1 1 1 400
11 CONDENSER COIL 61850320 1 1 410
11 CONDENSER COIL 62050209 1 410
11 CONDENSER COIL 62050201 1 1 410
11 CONDENSER COIL 61850203 1 410
* DRIER, LIQUID 60308101 11111 480
DRIER/CK VALVE/ CAP TUBE 92500001 1
* REVERSING VALVE 25018701 1 500
* CAPILLARY TUBE 03760473 2 2 471
* CAPILLARY TUBE 01390005 2 2 2 471
