LARGE CHASSIS "L" SERIES PARTS LIST
* PARTS NOT SHOWN
LARGE CHASSIS 208.230 VOLT 2006
REF DESCRIPTION PART NO# SL 230 EL 230 CODE
CHASSIS PARTS
SL25L30-B
SL28L30-A
SL36L30A-A
EL25L35-B
EL36L35A-A
YL24L35-A
* SHROUND, W/SUMP LRG 61807702 111111 720
13 FAN BLADE, COND. 60542007 111111710
14 BLOWER WHEEL, EVAP. 60610602 1111700
14 BLOWER WHEEL, EVAP. 60610609 1 1 700
15 BRACE, COND.SHROUD 61810000 333333 722
16 SCROLL 61818100 111111 743
17 BLOWER FRONT 61817800 111111 742
25 BRACKET, HTR 61818900 1 1 1 999
27 BASE PAN 61807101 1 730
27 BASE PAN 61807104 1 1 730
27 BASE PAN 61809501 1 730
27 BASE PAN 61809503 1 1 730
* BELLOWS, DRAIN VALVE 60179903 1 1 1 801
* DRAIN PAN, EVAP. 61807400 111111 840
* GRILLE, REAR 61818502 111111 771
29 PANEL, CTRL. MOUNT 61806950 111111 999
31 PARTITION, CTRL. BOX 61807000 1 1 1 999
31 PARTITION, CTRL. BOX 61807001 1 1 1 999
32 DECORATIVE PANEL 61822650 1 1 1 999
32 DECORATIVE PANEL 61823300 1 1 1 999
33 KNOBS, CRTL. 61493905 222222761
* BRACKET,RESISTOR BLK 61820600 111111 999
23 MOUNT, FAN MOTOR 61806700 111111 900
* HOLDER, AIR FILTER 61823000 222222 756
* FILTER, AIR 60865810 111111 754
* CLAMP, SUPPLY CORD 91500306 1 1 999
* CLAMP, SUPPLY CORD 91500308 1111999
34 GROMMET, COMP. 01150934 333333 790
35 SCREW, COMP. 91400400 333333999
