PERFORMANCE DATA
PERFORMANCE
DATA* Cooling
EVAP. AIR TEMP. DEG. F
CONDENSER
TEMPERATURE
DEG. F
Discharge
Temp
Suction
Temp
Super
Heat
Sub-
Cooling
OPERATING
PRESSURES
ELECTRICAL RATINGS
R-22 REF.
Voltage
BREAKER
FUSE
Discharge
Air
Temp.
Drop F.
Suction Discharge
Amps
Cool
Amps
Heat
Locked
Rotor Amps
Charge
in OZ.
60 Hertz
Amps
Q-Chassis
XQ05L10A-B 56 24 119 151 58 13 20 89 255 4.9 28.0 21.4 115 15 XQ06L10A-A 55 26 121 157 65 13 27 87 261 5.0 24.0 21.0 115 15 XQ08L10A-A 52 29 128 167 60 13 33 81 283 6.8 36.2 22.1 115 15 XQ10L10A-A 50 31 130 176 65 20 29 75 287 9.2 44.0 19.2 115 15 XQ12L10A-A 51 29 126 166 51 6 30 75 271 11.0 56.0 31.0 115 15 EQ08L11A-A 52 29 124 173 69 21 29 82 283 6.5 10.7 36.2 20.0 115 15 YQ07L10A-A 55 25 126 177 73 26 23 79 275 6.8 5.6 36.2 19.5 115 15 YQ07L10A-B 55 25 126 177 73 26 23 79 275 6.8 5.6 36.2 19.5 115 15
S-Chassis
SS08L10-C 56 24 119 154 73 22 24 85 252 6.6 36.2 23.0 115 15 SS08L10-D 56 24 116 157 68 16 18 86 250-260 6.6 36.2 27.0 115 15 SS10L10-C 57 23 117 166 65 16 23 82 243 7.5 42.0 26.0 115 15 KS12L10-C 52 29 122 169 61 13 24 82 266 9.0 44.0 26.5 115 15 SS12L10-D 53 27 124 169 62 13 30 82 266 9.3 44.0 32.0 115 15 KS15L10-B 51 30 125 182 62 16 29 77 278 12.2 61.0 29.0 115 15 SS14L10-C 53 27 125 184 62 15 27 78 268 12.3 61.0 29.2 115 15 SS12L30-C 57 24 121 170 67 17 27 83 258 5.4 21.0 28.0 208 / 230 15 SS12L30-D 58 22 122 174 66 17 28 84 261 4.7 21.0 31.0 208 / 230 15 SH15L30-B 54 26 206 129 61 16 98 76 258 8.2 28.5 208 / 230 15 SS16L30-C 50 31 130 176 53 8 35 77 279 7.9 35.0 32.1 208 / 230 15 ES12L33-B 56 25 121 167 65 15 28 83 256 4.8 15.1 21.0 28.0 208 / 230 20 ES12L33-C 58 22 122 174 66 17 28 84 261 4.7 15.1 21.0 31.0 208 / 230 20 ES16L33-B 49 32 130 179 50 8 34 75 279 7.4 15.1 35.0 32.0 208 / 230 20 YS09L10-D 60 20 116 164 71 18 17 89 239 7.1 8.5 44.0 25.1 115 15 YS13L33-B 58 23 123 175 69 22 29 79 266 5.2 5.3 / 15.1 24.0 30.0 208 / 230 20 YS13L33-C 51 29 122 172 65 18 30 80 269 5.5/5.1 5.7/5.3 24.0 32.0 1 20
M-Chassis
KM24L30-B 50 31 132 187 56 14 37 70 287 11.2 68.0 53.0 208 / 230 20 YM18L34-B 49 31 125 182 64 22 27 72 271 8.5 8.7 / 18.6 41.0 43.0 208 / 230 30 YM18L34-C 61 19 126 187 67 24 28 73 280 9.2/8.75 8.8/8.3 41.0 43.0 208/230 30 EM18L34-B 49 31 125 175 63 21 31 72 271 8.1 18.9 42.0 39.5 208 / 230 15 KM18L30-B 49 31 125 175 63 21 31 72 271 8.1 42.0 39.5 208 / 230 15 SM18L30A-B 53 28 122 175 66 13 25 82 255 7.3 37.0 44.0 208 / 230 15 SM18L30A-C 54 26 121 171 61 13 25 81 262 7.7/7.1 37.0 45.0 208/230 15 SM21L30-C 50 31 127 185 57 15 34 73 274 9.4 43.0 45.0 208 / 230 15 SM21L30-D 48 32 125 173 52 13 25 75 278 9.6/9.3 43.0 43.0 208/230 15 EM24L35-B 50 31 132 187 56 14 37 70 287 11.2 25.0 68.0 53.0 208 / 230 30 SM24L30-B 50 31 132 187 56 14 37 70 287 11.2 68.0 53.0 208 / 230 20
L-Chassis
SL28L30-C 53 28 128 172 56 13 29 73 259 13.0 68.0 50.1 208 / 230 20 SL36L30A-C 49 31 133 192 53 12 37 70 287 17.2 91.0 57.6 208 / 230 30 EL36L35A-C 49 32 133 194 53 13 38 70 302 18.0 25.0 91.0 60.0 208 / 230 30 YL24L35-C 52 29 122 175 65 23 29 72 262 10.9 11.2 / 24.6 68.0 74.0 208 / 230 30 YL24L35-D 52 28 124 175 65 22 29 74 268 11.9/11.1 11.7/11.0 68.0 73.0 208/230 30
HazardGard
SH15L30-B 54 26 206 129 61 16 98 76 258 8.2 28.5 208 / 230 15 SH20L30-B 46 34 125 196 52 8 28 75 271 10.1 39.0 208 / 230 20
*Rating Conditions: 80 degrees F, room air temp. & 50% relative humidity, with 95 degree F, outside air temp & 40% relative humidity.
