9
CONFIGURING THE ENERGY SAVING SETTINGS
➤ Use the “Up” and “Down” buttons to select the Energy Saving preset:
E-0 Energy Savings Off - No Temperature Setback;
E-1 Lowest Energy Savings;
E-2 Lower Energy Savings;
E-3* Standard Energy Savings;
E-4 Higher Energy Savings;
E-5 Highest Energy Savings;
Refer to the APPENDIX 1 for Energy Saving Preset details.
E-C Indicates “Custom Energy Savings Settings” in case the active thermostat savings
settings differ from any Energy Saving preset;
For details, refer to the “Custom Energy Savings Settings” section;
➤ Press the “Power” button to save the Thermostat Conguration and start using the
thermostat;
* Indicates factory setting;
TESTING THE THERMOSTAT
Following the thermostat conguration, test if the thermostat is controlling the PTAC unit.
➤ Press the “Power” button to turn the thermostat ON;
➤ Press the “Up” and “Down” buttons to change the temperature setpoint above and below
the current room temperature to test if the thermostat initiates heating and cooling - the
PTAC unit should turn heating and air conditioning on and off.
➤ Change the fan speed by touching the “Fan” button to test if the thermostat is controlling
the fan speed.
Thermostat Conguration
