—15—
3. Loosely assemble the sill support using the parts
in
Figure 22.
4. Select the position that will place the sill
support near the outer most point on sill
(See
Figure
22)
NOTE: Be careful when you install the cabinet
(Frame Guides
are broken easily).
5. Attach the sill support to the cabinet track hole in
relation to the selected position using
2 Type A screws in each support (See
Figure 23).
6. The cabinet should be installed with a very slight
tilt (about
1
/2") downward toward the outside
(See Figure 24).
Adjust the bolt and the nut of Sill Support for
balancing the cabinet.
7. Attach the cabinet to the window stool by
driving the screws (Type B: Length sixteen
millimeters and below.) through the front angle into
window stool (5/8").
8. Pull each Frame Curtain properly to each
window sash track, and repeat step 2.
9. Attach each Frame Curtain to the window sash
by using screws (Type C).
(See Figure 25)
Figure 22
Figure 23
Figure 24
Figure 25
